AUDIOCENTER PRO4.0. 1600Watt Power Amplifier

Name: AUDIOCENTER PRO4.0. 1600Watt Power Amplifier
Brand: Audiocenter
SKU: PRO4.0
Price: 1599.00 NZD
Availability: OutOfStock

$1,599.00

Sale Sold out

Taxes included. Shipping calculated at checkout.

Overview

PRO4.0 offers 400 watts at 8Ω stereo. Each channel works at 2Ω to satisfy all requirements. PRO4.0 adopts Audiocenter latest Class H+ circuitry to eliminate the Class H cross switching distortion. PRO4.0 has very clear and clean sound and high damping factor. This makes PRO4.0 suitable for any kind of application, from high power loudspeakers to critical monitoring where very high requirements are mandatory. It can be widely used in fixed installation and touring performance such as bar, nightclub, multi-functional hall, museum, religious venue, commerce site, lecture hall, wedding ceremony, etc.

Features

A-Guard Protection System

A-Guard is Audiocenter comprehensive protection system which includes optimized limiter circuit. Unlike other solutions which depend on separate circuits to address different problems, A-Guard was developed as centralized solution where all protection requirements work together in perfect harmony. A-Guard is only applied when it’s necessary to protect the amplifier. This is the reason why PRO amplifiers are able to sustain full power output even under complex capacitive loads.

Smart Overheat Management

The smart overheat management of PRO series adopts unique circuitry to monitor the amplifier’s temperature in real time. When the safe operation of the amplifier is compromised, the output power is reduced but not shut down, which ensures the system can work normally in high temperature environment.

Class H+ Circuit Design Eliminates Cross Switching Distortion

PRO series adopts Audiocenter latest Class H+ circuit to eliminate the Class H cross switching distortion. The result is the same low distortion as Class AB. All PRO amplifiers have less than 0.05%THD at 16KHz and the sound is so clean and natural.

Core Components

Specifications

Rated Power(20Hz-20kHz, <0.1%THD)	2×400W@8Ω stereo 2×600W@4Ω stereo 2×800W@2Ω stereo 1200W@8Ω bridge 1600W@4Ω bridge
A-Guard Protection System	DC protection / Short circuit protection / Smart overheat management / Overheat protection / Input overload protection / Output overload protection / Soft startup protection / Limiter protection Up to 9V
Frequency Response(1W 8Ω stereo)	20Hz-20kHz(±0.5dB)
Sensitivity	0.775V / 32dB / 26dB
Input Connectors Output Connectors	Male XLR & female XLR 3× Speaker connector
Filter Capacitor Capacity	10000μf / 50V×8
Input Impedance	Balanced 20kΩ / Unbalanced 10kΩ
Crosstalk(20Hz-20KHz, Rated power 8Ω)	≥65dB
S/N Ratio(Rated power 8Ω, A weighted)	≥108dB
Damping Factor (1kHz&8Ω)	≥500
Intermodulation Distortion(20Hz-20kHz, half power)	≤0.05%
Total Harmonic Distortion(20Hz-20kHz, rated power 8Ω)	≤0.05%
Phase Response(1W&8Ω, 20Hz-20kHz)	20Hz+4° 20kHz-12°
Slew Rate	≥45V/μs
Output Circuitry	Class H+
Power Consumption(Dual channel driven 4Ω,1/ 8RMS / 230V)	1.8A
Rack Space	2U
Cooling	Back to front venting, mandatory cooling
Dimension (W×H×D)	483×88×456mm
Net Weight	18.0Kg
